Light-generating reporter molecules ease cell monitoring

Chemiluminescent reagents help track activity in cells

by Stu Borman
March 16, 2017 | A version of this story appeared in Volume 95, Issue 12

Illuminating reaction

Schematic shows how a reaction caused by an analyte or enzyme removes the protecting group from a Schaap’s reagent bearing an electron-withdrawing group, producing an unstable intermediate that chemiluminescences brightly in aqueous solution and in cells.
Credit: ACS Central Science
Removing the protecting group (PG) from a Schaap’s reagent bearing an electron-withdrawing group (EWG) produces an unstable intermediate that chemiluminesces.

To detect the goings-on inside cells without an external light source, scientists can genetically engineer cells to produce chemiluminescent reporter molecules. A new class of small molecules, however, can penetrate cells and monitor their biological processes by chemiluminescence, avoiding genetic modification.

Chemiluminescence, the process that lights up glow sticks, occurs when a chemical reaction generates light. Researchers use it to monitor reactive oxygen species and diagnose pathogenic infections, as well as for detection in chromatography, electrophoresis, immunoassay, nucleic acid assay, and blotting experiments.

The new reagents are modified versions of widely used chemiluminescent Schaap’s adamantylidene-dioxetanes, each of which has a characteristic protecting group that reacts when a specific enzyme or reactive compound is present. For example, the protecting groups may be substrates for a particular enzyme. When that enzyme is present, it cleaves the protecting group from the Schaap’s reagent, yielding an unstable phenolate-dioxetane that chemiluminesces.

Schaap’s reagents work well in organic solvents but emit light only weakly in water. Three-component systems—each a mixture of a Schaap’s reagent, a surfactant, and an excitable fluorescent dye—shine about 100 times as brightly in water as Schaap’s reagents by themselves, but the mixtures aren’t used in cells because they are toxic. Scientists can also use the firefly substrate-enzyme pair luciferin and luciferase to monitor gene expression and other processes inside cells, but they must first engineer the cells to produce luciferase.

Doron Shabat of Tel Aviv University and coworkers at the University of Geneva have now brightened up Schaap’s reagents in a way that permits their use in cells (ACS Cent. Sci. 2017, DOI: 10.1021/acscentsci.7b00058).

The team adds electron-withdrawing substituents to conjugated positions on the reagents’ phenolate group, creating long π-electron systems that emit more light in water-based media. One modified reagent, with added acrylonitrile and chlorine groups, emits in aqueous solution 1,000 times as much light as a conventional Schaap’s reagent and 10 times as much as a three-component system. It is nearly as bright as luciferin-luciferase, it can simply diffuse into cells, and it doesn’t require genetic engineering.

“This is a game changer for chemiluminescent diagnostics,”says Phil S. Baran of Scripps Research Institute California, who collaborated with Shabat on a previous project.

By adding different protecting groups as triggering substrates for various enzymes or reactive compounds, Shabat and coworkers used the new reagents to image β-galactosidase activity in single cells and to detect alkaline phosphatase, glutathione, and hydrogen peroxide in aqueous solution.

“This simple and elegant molecular design provides a dramatic enhancement,” comments Alexander R. Lippert of Southern Methodist University. “No excitation light source is needed,” eliminating several problems associated with fluorescence-based cell analysis, including signal fading, toxicity, and background interference, he says.

Shabat and coworkers hope to extend the molecules’ light emission range from the visible to the near infrared to improve their ability to penetrate tissue deeply for possible in vivo use.
